Guangdong KONDARL Agriculture and Animal Husbandry Technology Co., Ltd

Time2021-06-01     Reserved   Read


Guangdong KONDARL Agriculture and Animal Husbandry Technology Co., Ltd ordered a set of Xin Yuan SWFL150 ultrafine pulverizer system (with a main power of 160kw) from our company in June 2016. On September 7, 2016, production capacity acceptance was conducted: white shrimp feed: 95% pass 80 mesh, with a production capacity of 5.71 t/h.





The technical service team ofNEW XIN YUANarrived at Guangdong KONDARL Agriculture and Animal Husbandry Technology Co., Ltd on November 13, 2016 for follow-up services.


NEW XIN YUANTechnical service personnel entered into the center control room, observed the crushing system, and communicated with production technicians to understand the current production needs.


NEW XIN YUAN Technical service personnel entered the equipment site and conducted a series of inspections and maintenance from the system exterior to the interior of the equipment. The main unit had no abnormalities in appearance, and the noise and vibration were normal.


Foreign object discharge device: Reasonable adjustment of the air supplement door

Aspiration system: no wear and air leakage, reasonable bending radius





Pulse dust removal: The equipment was normal and there was no air leakage


Pulse solenoid valve: working normally, the soft connection clamp of the solenoid valve was not loose


Internal inspection of equipment

Tooth ring, hammer, and wear-resistant plate: normal wear and tear


Grading wheel: Normal wear and no adhesion


Settlement chamber: slight residual foreign matter


Pulse: The interior of the sleeves were intact, with slight sticking of material


Cylinder: No water accumulation


NEW XIN YUANAfter a series of inspection and maintaining, that your company's current system equipment running normally,we give some suggestions as below:

1Clean the inner structure of pulverizer timely. Adjust the air supplement door properly according to feed.

2. Check the process of pulverizer, pulse dust collector and flexible connection of solenoid valve on schedule. Pay attention to the pressure and ponding condition of pulse air cylinder.

3. The test of fineness should according to strict standard of quality control.

4. Technologist should inspect the inner structure and working processing every day. Check whether the rough grinding sieve is broken or not and keep record.


Our quality assurance & inspection completed successfully. We appreciate Guangdong KONDARL Agriculture and Animal Husbandry Technology Co., Ltd for supporting and communication with us. We will continue to pay attention and serve with dedication. "

Xin Yuan people, dedicated to serving you" - "May our service be with you at any time".
